Mammut RF3

The mammoth among agitators.

An agitator in the fermenter is important to ensure an optimum supply of nutrients and a homogeneous fermentation substrate throughout the fermenter.

Fermenterrührwerk für Biogasanlagen: Mammut RF3
Fermenterrührwerk Mammut im Einsatz bei Biogasanlage
Das Mammut Fermenterrührwerk als Wandkonstruktion in Biogasanlage
Paulmichl Fermenterrührwerk Mammut Biogasanlage Außenansicht
Rührwerk im Fermenter: Innenansicht einer Biogasanlage
Bedienelemente zum Steuern des Fermenterrührwerks in Biogasanlage
Wandeinbau des Mammut Fermenterrührwerks

As strong as a mammoth

Advantages of the fermenter agitator

  • Ideal for constant fill level
  • Powerful, high-quality and highly efficient
  • Reliable agitating performance with high dry matter content
  • Gentle stirring effect
  • robust & durable
  • stepless & hydraulic adjustment option
  • Wall and ceiling installation possible



The Mammut RF3 is particularly suitable for constant fill levels. The robust design and the infinitely variable, hydraulic adjustment of the agitator enable optimum adaptation to your fermenter substrate. The agitator is installed in the fermenter without wear-prone base or counter bearings and is uncomplicated thanks to its simple handling. The agitator is mounted on the installation bracket with a vibration bearing. The agitator blade rotates particularly slowly and gently with the same efficient operation. This enables you to achieve lower power consumption and increased longevity.

Mammut x Multimix: Unbeatable combination

An unbeatable team for your biogas plant is the combination of the Mammut agitator in the fermenter and the Multimix agitator in the secondary fermenter and final storage tank. The Multimix can be used to ensure optimum temperature and nutrient distribution for changing fill levels (secondary fermenter).

Technical data

  • Standard: vertical hydraulic adjustment device with hand pump and control unit
  • Standard length: 3.30 or 4.50m
  • Agitator blade diameter from 1,600 - 1,800 mm
  • Drive power: 22 kW

Das Fermenterrührwerk Mammut RF3 für den effizienten Betrieb

Das Mammut RF3 eigent sich besonders bei gleichbleibendem Füllstand. Durch die robuste Konstruktion und die stufenlose, hydraulische Verstellmöglichkeit des Rührwerks kann eine optimale Anpassung an dein Fermentersubstrat erzielt werden. Der Einbau des Rührwerks erfolgt ohne verschleißanfällige Boden- oder Gegenlager im Fermenter und ist dank der einfachen Handhabung unkompliziert. Das Fermenterrührwerk ist schwingungsgelagert auf der Einbauhalterung montiert. Der Rührflügel dreht besonders langsam und schonend bei gleich effizientem Einsatz. Dies ermöglicht dir einen geringeren Stromverbrauch sowie eine erhöhte Langlebigkeit.

Mammut x Multimix: Unschlagbare Kombi

Ein unschlagbares Team für deine Biogasanlage ist die Kombination des Mammut-Rührwerkes im Fermenter und das Multimix-Rührwerk im Nachgärbehälter und Endlager. Mit dem Multimix kann die optimale Temperatur- und Nährstoffverteilung für wechselnde Füllstände (Nachgärbehälter) sichergestellt werden.
